MicroSmart YAG Laser Systems
What Is It?
- Model 20 : 20 Watt Average Power
- Model 10 : 10 Watt Average Power
- Model 5 : 5 Watt Average Power
Take a look at our diode pumped solid state YAG Laser Systems that require only air-cooling. This system does not require a water chiller.
Features
- Highly efficient system requiring only air cooling. Required electrical power supply is 110 VAC, single phase or 220 VAC, single phase
- Average diode pump life of 10,000 - 15,000 working hours
- Sealed optical resonator with 1064nm wavelength lasr power as well as red pointer diode
- Electrically controller shutter
- Laser power generation unit is the size of a large PC computer that is easily manageable
- High quality galvo marking head with standard 160mm, F-theta objective with an approximate working area of 4.5" x 4.5"
- PC requirements are Windows 98 or ME operating system with a minimum processor speed of 600 MHz, 128MB RAM Memory, USB Port, at least 1 PCI Slot, CD-Rom, Hard Disk Drive, Mouse, Keyboard, and Monitor with resolution of at least 800 x 600.
- MaxMotion Marking/Engraving software with many of its classic and state-of-the-art features and functions to get the most out of the system
Technical Characteristics
- MicroSmart YAG
- 1
- 2
- 3
- Output Wavelength
- 1064 nm
- 1064 nm
- 1064 nm
- Average Power
- 5 Watt
- 10 Watt
- 20 Watt
- Frequency
- 20 KHz
- up to 200 KHz
- up to 300 KHz
- Beam Quality
- TEMoo
- Lower Order Mode
- Lower Order Mode
- Red Pointer Beam
- 635 nm - Class 1
- 635 nm - Class 1
- 635 nm - Class 1
- Marking Speed
- up to 1000 mm/sec
- up to 1000 mm/sec
- up to 1000 mm/sec
Available Options
- Enclosures
- Various focal lengths F-theta objectives
